Tektronix DPO2012B User Manual

Installation
Optional Accessories
Accessory Description Tektronix part number
DPO2EMBD
The embedded serial triggering and analysis module
enables triggering on packet level information on
I
2
C and SPI ser
ial buses, as well as bus views, bus
decoding, search tools, and packet decode tables
with timestamp information
DPO2EMBD
DPO2AUTO
The automotive serial triggering and analysis module
enables triggering on packet level information on
CAN and LIN se
rial buses, as well as bus views, bus
decoding, search tools, and packet decode tables
with timestamp information
DPO2AUTO
DPO2COMP
The computer triggering and analysis module
enables triggering on RS-232, RS-422, RS-485 and
UART seria
l buses, search tools, bus views, bus
decoding in hex, binary, and ASCII, and decode
tables with timestamp information
DPO2COMP
DPO2CO NN
The connectivity module adds an Ethernet port
for remote programmability and a Video Out port
to displa
y the oscilloscope screen on an external
monitor
DPO2CO NN
NEX-HD2H
EADER
Adapter that routes the channels from a Mictor
connector to 0.1 inch header pins
NEX-HD2H
EADER
TekVPI probes that work
with MSO/DPO2000B Series
oscill
oscopes
Note: These probes require the
use of the TekVPI external power
adapte
r listed below.
Visit the Oscilloscope Probe and Accessory S elector
Tool on
the Tektronix website at www.tektronix.com.
TekVPI external power adapter
Suppl
ies external power to a TekVPI probe
119‑7465‑XX
TPA-B
NC
Note: This adapter requires the
use of the TekVPI external power
adap
ter listed above.
TekVP
I to TekProbe II BNC Adapter
TPA-B
NC
Deskew pulse generator Deskew pulse generator and signal source with
TekV
PI oscilloscope interface
TEK-
DPG
Power measurement deskew and
cal
ibration fixture
Con
verts TEK-DPG pulse generator output into a
series of test point connections
067-1686-00
TEK-USB-488 A dapter GPIB to USB Adapter TEK-USB-488
Ra
ckmount kit
Ad
ds rackmount brackets
RM
D2000
S
oft transit case
C
ase for carrying an oscilloscope
A
CD2000
Hard transit case
T
raveling hard case, which requires use of the soft
transit case (ACD2000)
H
CTEK4321
MSO2000B and DPO2000B Series Oscilloscopes User Manual 3
