Tektronix DPO3000 Series User Manual

Acquire the Signal
Changing the Acquisition Mode, Record Length, and Delay Time
Use this procedure to change the acquisition mode.
1. Push Acquire.
2. Push Mode.
Mode
Sample
Record
Length
10k
Delay
On |
Off
Set Horiz.
Position to
10%
Waveform
Display
XY Display
Off
90 DPO3000 Series Oscilloscopes User Ma nual
