Preface
Preface
This manual describes the installation and operation of the following oscilloscopes:
DPO3054 DPO3052 DPO3034 DPO3032
DPO3014 DPO3012
Key Features
DPO3000 series instrum ents can help you verify, debug, and characterize electronic designs. Key features include:
500 MHz, 300 MHz, and 100 MHz bandwidths
2 a nd 4 channel models
Sample rates up to 2.5 GS/s on all analog channels
5 M points record length on all channels
50,000 waveforms/second d isp lay rate
I
2
C, SPI, CAN, LIN, RS-232, RS-422, RS-485, and UART bus triggering and analysis (with the appropriate a pplication
module and model oscilloscope)
Wave Inspector controls for managing long record len gths, with zoom and pan, play and pause, search and mark
229 mm (9 inch), with 800 x 480 resolution, WVGA color display
Small and lightweight, at 127 mm (5 inches) de ep and 4.1 kg (9 pounds)
USB available for quick and easy storage
x DPO3000 Series Oscilloscopes User Ma nual
