Analyze Waveform Data
Customizing an Automatic Measurement
You can customize automatic measurements by using gating, modifying measurement s tat istics, adjusting the measu rement
reference levels, or taking a snapshot.
Gating
Gating confines the measurement to a certain portion of a w aveform. To use:
1. Push Measure.
2. Push More as many time s as needed t o select
Gating from the resulting pop-up menu.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors On
Screen
Configure
Cursors
DPO3000 Series Oscilloscopes User Manua l 163
