Tektronix DPO3000 Series User Manual

Analyze Waveform Data
Description Window
Blackman-Harris:
This is the best window for measuring the amplitude of frequencies but worst at re solving
frequencies.
Use Blackman -Harris for measuring pre dominantly single frequency waveforms to look for higher
order harmonics.
Using Advanced Math
The advanced math feature lets you create a custo m math waveform expression that can incorporate active and reference
waveforms, measurements, and/or numeric constants. To use this feature:
1. Push Math.
184 DPO3000 Series Oscilloscopes User Ma nual
