Tektronix DPO3000 Series User Manual

Trigger Setup
3. Push Type.
Type
Bus
Source Bus
B1 (I2C)
Trigger On
Address
Address
07F
Direction
Write
Mode
Auto
& Holdoff
4. Turn multipurpose kn ob a to scroll through the
trigger type side menu until you select Bus.
B1 (I2C)
5. Push Source Bus and turn multipurpose knob
a to scroll through the source bus side menu
until you select the bus that you w ant to trigger
on.
B2 (CAN)
122 DPO3000 Series Oscilloscopes User Ma nual
