Save and Recall Information
RF1, RF2, RF3, or RF4 for reference memory waveforms
ALL f or a single spreadsheet file containing multiple channels when you select S ave All Waveforms
NOTE. Only analog channels a nd waveforms derived from analog channels (su ch as math and reference) can be saved to an ISF
file. When saving a ll channels in ISF format, a gro up of files will be saved . Each will have the same value for XXXX, but the YYY
values will be set to the different channels that were turned on when the Save All Waveforms was p erformed.
For example, the first time you save a file, that file is named tek00000. The next time you save the same type of file, the file will
be named tek00001.
Editing File, Directory, Reference Waveform, or Instrument Setup Names. Give files descriptive names that you can
recognize at a later date. To edit file names, dire ctory names, reference waveform and instrument setup labels:
1. Push Save / Recal l M enu.
200 DPO3000 Series Oscilloscopes User Ma nual
