Application E xamp les
Taking Cursor Measure ments
You can use the cursors to take quick measurements on a waveform. To measure the ring frequency at the rising edge of the signal:
1. Push channel 1 to select the channel 1 signal.
2. Push Measure.
3. Push Configure Cursors.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors On
Screen
Configure
Cursors
246 DPO3000 Series Oscilloscopes User Ma nual
