Tektronix DPO3000 Series User Manual

Appendix: Warranted Specifi cations, Safety Certifications, and Electroma gnetic Compatibility
Input im pedance, DC
coupled
1MΩ ±1%inparallelwith11.5pF±2pF
75 Ω ±1%
VSWR ≤ 1.3:1 from D C to 60 MHz, typical
50 Ω ±1%
DPO3054, DPO3052: VSWR ≤ 1.5:1 from DC to 500 MHz, typical
DPO3034, DPO3032: VSWR ≤ 1.5:1 from DC to 350 MHz, typical
DPO3014, DPO3012: VSWR ≤ 1.5:1 from DC to 100 MHz, typical
DC Balance 0.2 div with the input DC-50 Ω coupled and 50 Ω terminated
0.2 div with the input DC-75 Ω coupled and 75 Ω terminated
0.25 div at 2 mV/div with the input DC-50 Ω coupled and 50 Ω terminated
0.25 div at 2 mV/div with the input DC-75 Ω coupled and 75 Ω terminated
0.5 div at 1 mV/div with the input DC-50 Ω coupled and 50 Ω terminated
0.5 div at 1 mV/div with the input DC-75 Ω coupled and 75 Ω terminated
0.2 div with the input DC-1 MΩ coupled and 50 Ω terminated
0.3 div at 1 mV/div with the input DC-1 MΩ coupled and 50 Ω terminated
DC Ga in accuracy ±2.5% for Coarse setting of 1 mV/div, derated at 0.100%/°C above 30 °C
±2.0% for Coarse setting of 2 mV/div, derated at 0.100%/°C above 30 °C
±1.5% for Co arse settings of 5 mV/div a nd above, derated at 0.100%/°C above 30 °C
±3.0% for all Fine V/div settings, derated at 0.100%/°C above 30 ° C
274 DPO3000 Series Oscilloscopes User Ma nual
