DC gain accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch2 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
Ch2 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
Ch2 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+ 1.49 V
+ 1.49 V
+ 1.49 V
__________
__________
__________
__________
__________
__________
+ 1.55 V
+ 1.55 V
+ 1.55 V
Ch2 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+ 3.876 V
+ 3.876 V
+ 3.876 V
Ch3 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
Ch3 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
__________
__________
__________
__________
__________
__________
+ 155.04 mV
+ 155.04 mV
+ 155.04 mV
Ch3 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
Ch3 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
Ch3 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+ 1.49 V
+ 1.49 V
+ 1.49 V
__________
__________
__________
__________
__________
__________
+ 1.55 V
+ 1.55 V
+ 1.55 V
Ch3 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+ 3.876 V
+ 3.876 V
+ 3.876 V
Ch4 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
