Tektronix DPO5000 Series Technical Reference

<4 GHz models Total:
<1 ps rms for record durations less than 10 μs.
<2.5 ps rms for record durations less than 30 ms.
<65 parts/trillion for record durations less than 10 s.
Jitter noise floor, typical, ≥4 GHz
models
Applies to time periods as long as 10.0 μs. Typical jitter noise floor is measured at the maximum,
BWE enabled bandwidth:
MSO/DPO70000DX models
MSO/DPO73304DX
MSO/DPO72504DX
MSO/DPO72304DX
<323 fs
<364 fs
<378 fs
Calculate the jitter noise floor (JNF) for a given instrument setting using the following formula:
Ntyp = typical input-referred noise spec (volts rms)
FN = 1.3 for instrument bandwidth ≤9 GHz; 1.5 for instrument bandwidth ≥10 GHz
SR = slew rate around the measurement
FI = (1.7 x 10–2)/sqrt(2) = 1.2 x 10–2
tr = rise time of the measurement edge
tj = timebase jitter or aperture uncertainty
TBA = timebase accuracy (2 ppm)
JNF
RMS
= (N
typ
× F
N
)
2
×
(
1
SR
)
2
+ F
I
2
× t
r
2
+ t
j
2
seconds
RMS
The interpolated sample rate of the waveform must be at least 25 times the bandwidth of the signal
being measured.
MSO/DPO70000C models
MSO/DPO72004C at 20 GHz 400 fs
MSO/DPO72004C,
MSO/DPO71604C
at 16 GHz
300 fs
MSO/DPO71254C at 12.5 GHz 300 fs
MSO/DPO70804C
MSO/DPO70604C
MSO/DPO70404C
450 fs
Calculate the jitter noise floor (JNF) for a given instrument setting using the following formula:
FS = full-scale setting (volts)
A = signal amplitude as a fraction of full-scale
trm = 10 - 90% displayed (or measured) rise time (seconds)
N = input-referred noise (volts rms)
tj = short term timing jitter (seconds rms)
JNF
RMS
=
N
FS × A
× t
rm
2
+ t
j
2
seconds
RMS
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Horizontal and acquisition system
(cont.)
52 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
