Tektronix DPO7000 Series Service Manual

Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Table 5-17: Rep
laceable parts – Front panel (MSO70000/C, DSA/DPO70000C Series)
Fig. & index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont’d Qty Name & descrip
tion
5-19-
FRONT PANEL AN
D DISPLAY
-1 174-5165-00 1
CABLE ASSY; POWER SWITCH
-2 065-0756-02 1
MODULE ASSY;SERVICE REPLACEMENT KIT,614104101 FRONT PANEL
ASSEMBLY W/ PACKAGING;DPO7000,DPO/DSA70000 SERIES
-3 366-0859-0
1
1
ASSEMBLY, KNOB; .470 DIAMETER, SOFT TOUCH
-4 366-0860-01 1
ASSEMBLY, K
NOB; .685 DIAMETER, SOFT TOUCH
-5
366-0861-01 1
ASSEMBLY, KNOB; .925 DIAMETER, SOFT TOUCH
-6 174-5162-
00
1
CABLE ASSY; DISPLAY ADAPTER TO FRONT PANEL BOARD
-7
065-0827-01 1
COMPONENT
KIT; LCD DISPLAY ADAPTER MODULE SUBASSEMBLY,
STANDARD
-8 065-0819-00 1
MODULE AS
SY;SERVICE REPLACEMENT KIT,POWER BUTTON ASSY
W/ PACKAGING, FOR ADVANTECH AIMB-562 MOTHERBOARD
-9 211-1050-00 2
SCREW, MA
CHINE; 6-32 X 0.312 L, PNH, STEEL, ZINC FINISH, T15
5–36 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
