Replacement parts are available from or through your local
Tektronix , Inc. Field Office or representative .
Changes to Tektronix instruments are sometimes made to
accommodate improved components as they become available ,
and to give you the benefit of the latest circuit improvements
developed in our engineering department . It is therefore impor
tant , when ordering parts , to include the following information in
your order : Part number , instrument type or number , serial
number , and modification number if applicable .
If a part you have ordered has been replaced with a new or
improved part , your local Tektronix , Inc. Field Office or represen
tative will contact you concerning any change in part number .
Change information , if any , is located at the rear of this
manual .
LIST OF ASSEMBLIES
A list of
assemblies
can
be found at
the
beginning of the
Electrical Parts List . The assemblies are listed in numerical order .
When the complete component number of a part is known , this list
will identify the assembly in which the part is located .
CROSS
INDEX
-
MFR .
CODE
NUMBER TO
MANUFACTURER
The Mfr .
Code
Number
to
Manufacturer index for the
Electrical
Parts List is
located immediately
after this
page
.
The
Cross Index provides codes , names and addresses of manufac
turers of components listed in the Electrical Parts List .
REPLACEABLE
ELECTRICAL PARTS
PARTS
ORDERING
INFORMATION
Abbreviations conform to American National Standard Y1.1 .
ABBREVIATIONS
COMPONENT
NUMBER (
column one of
the
Electrical
Parts
List
)
A
numbering
method
has
been used to
identify
assemblies
,
subassemblies and parts .
Examples
of this
numbering method
and typical expansions are illustrated by the following :
Example a .
component
number
A23
R1234
A23R1234
Assembly
number
Example
b .
A23A2R1234
Assembly
number
Read
:
Resistor 1234 of
Assembly 23
Circuit
number
A23
z
component
number
A2 R1234
Subassembly
Circuit
number number
Read
:
Resistor 1234 of
Subassembly 2 of
Assembly 23
Section 9 - FG 5010
Only the circuit number will appear on the diagrams and
circuit board illustrations . Each diagram and circuit board
illustration is clearly marked with the assembly number .
Assembly numbers are also marked on the mechanical exploded
views located in the Mechanical Parts List . The component
number is obtained by adding the assembly number prefix to the
circuit number .
The
Electrical Parts List is
divided and
arranged by
assemblies in numerical sequence ( e.g. , assembly A1 with its
subassemblies and parts , precedes assembly A2 with its sub
assemblies
and
parts
) .
Chassis - mounted parts have no assembly number prefix
and are located at the end of the Electrical Parts List .
TEKTRONIX PART NO
. (
column two of the
Electrical
Parts
List )
Indicates part number to be used when ordering replace
ment
part from Tektronix
.
SERIAL
/
MODEL
NO . (
columns
three and
four
of
the
Electrical
Parts
List )
Column three ( 3 ) indicates the serial number at which the
part was first used . Column four ( 4 ) indicates the serial number at
which the part was removed . No serial number entered indicates
part
is
good for all
serial
numbers .
NAME
&
DESCRIPTION (
column five of the
Electrical
Parts
List
)
In the Parts
List , an Item
Name is
separated
from the
description by a colon ( :) . Because of space limitations , an Item
Name may sometimes appear as incomplete . For further Item
Name
identification , the U.S.
Federal
Cataloging
Handbook
H6-1
can be utilized where possible .
MFR . CODE ( column six of the Electrical Parts
List )
Indicates the code number of the actual manufacturer of the
part . ( Code to name and address cross reference can be found
immediately after this page .
)
MFR
.
PART NUMBER (
column
seven
of
the
Electrical
Parts
List
)
Indicates actual manufacturers part number .
9-1
