Tektronix MDO3014 User Manual

Display Wavefor
morTraceData
2. Push Utility P
age.
Utility
Page
3. Turn Multipu
rpose a and select Display.
Display
4. Push Trigger Frequency Readout from the
resulting l
ower menu.
Utility
Page
Display
Backlight
High
Graticule
Full
Screen
Annotation
Trigger
Frequency
Readout
5. Push On on t
he side menu.
The trigger frequency now appears in the
Trigger r
eadout, toward the lower right of the
display.
Displaying the Frequency Domain Menu
1. Push RF to bring up the frequency domain
menu.
2. Push Spectrum Traces to bring up the side
menu of four different spectrum trace types
that the MDO3000 can display.
Spectrum
Traces
Spectro-
gram
Off
Spectrum
Free Run
Detection
Method
Auto
Edit Labels
More
3. Push Spectrogram to bring up a side menu
to enable and configure the spectrogram
display.
4. Push Detection Method tobringupaside
menu of ways to reduce the FFT output to
the 750 pixel wide d isplay.
5. Push Edit Label to label the RF traces.
6. Push More to choose between side menus
to compensate the RF signal path or to
configure the RF input probe.
MDO3000 Series Oscilloscopes User Manual 117
