Appendix C : P631
6 General-Purpose Logic P robe Information
Specifications
Table 8: Electrical and mechanical specifications
Characteristic Description
Input channels 16 digital input
Input resist
ance, typical
101K Ohm to ground
Input capac
itance
8pF
Input signal swing
Minimum, typical 500 mV p-p
Specified at the input to the P6316 probe with all 8 ground inputs connected
to the u s er
’s ground. Use of leadsets, grabber clips, ground extenders, or
other connection accessories may compromise this specification.
Maximum,
typical
+30 V, –20
V
Table 9: Environmental specifications
Characteristic Description
Temperature
Maximum operating
+50 °C (+122 °F)
Minimum operating
0°C(+32°F)
Non-operating
–40 °C to +71 °C (–40 °F to +159 °F)
Humidity
5% to 95% relative humidity at up to +30 °C (+86 °F)
5% to 60% RH above +30° C (+86 °F) up to +50 °C (+122 °F), non-condensing
Altitude
Operating 3,000 meters (9,843 feet)
Non-operating
12,000 meters (39,370 feet)
Equipment Recycling. This product complies with the European Uni on’s requirements according to Directive
2002/96/EC on waste electrical and electronic equipment (WEEE). For more information about recycling
options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).
Safety Summary
To avoid potential hazards, use this probe only as specified.
Connect and Disconnect Properly. Connect the probe output to the measurement instrument before connecting
the probe to the circuit under test. Disconnect the probe i nput and the probe ground from the circuit under test before
disconnecting the probe from th
e measurement instrument.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings and markings on the product. Consult
the product manual for further ratings information before making connections to the product.
MDO3000 Series Oscilloscopes User Manual 209
