Installation
Installation
Before Installation
Unpack the oscilloscope and check that you r eceived all items listed as standard accessories. The following pages list
recommended accessories and probes, instrument options, and upgrades. Check the Tektronix Web site (www.tektronix.com)
for the most current information.
Standard accessories
Accessory Description
Tektronix part
number
MDO3000 Installation and Safety Manual General installation and safety information
071-3249-XX
MDO3000 Series Oscilloscopes
Documentation Browser CD
Electronic versions of or links to documents,
including the User Manual, Programmer
Manual and the Technical Reference.
Tektronix OpenChoice Desktop CD
Productivity, analysis, and documentation
software
063-4526-XX
Calibration certificate documenting
traceability to national metrology institute(s),
and ISO9001 quality system registration.
––
French (Option L1)
335-3264-XX
Italian (Option L2)
335-3265-XX
German (Option L3)
335-3266-XX
Spanish (Option L4)
335-3267-XX
Japanese (Option L5)
335-3268-XX
Portuguese (Option L6)
335-3269-XX
Simplified Chinese (Option L7)
335-3270-XX
Traditional Chinese (Option L8)
335-3271-XX
Korean (Option L9)
335-3272-XX
Front Panel Overlay
Russian (Option L10)
335-3273-XX
For 100 and 200 MHz models, one 250 MHz,
10X passive probe per channel
Two TPP0250 for the MDO3012/22 and
four TPP0250 for the MDO 3014/24
TPP0250
For 350 and 500 MHz models, one 500 MHz,
10X passive probe per channel
Two TPP0500B for the MDO3032/52 and
four TPP0500B for the MDO3034/54
TPP0500B
Probes
For 1 GHz models, one 1 GHz, 10X passive
probe per channel
Two TPP1000 for the MDO3102 and four
TPP1000 for the MDO3104
TPP1000
Adapter
NMaletoBNCFemale
103-0473-XX
MDO3000 Series Oscilloscopes User Manual 1
