Tektronix MDO3014 User Manual

Installation
Optional application m odules
Tektronix p art number Description
MDO3AERO ARINC429 and MIL-STD-1553 Serial Triggering and Analysis
MDO3AUDIO Audio Serial Triggering and A nalysis (I
2
S, LJ, RJ, TDM)
MDO3AUTO Automotive Serial Triggering and Analysis (CAN, CAN FD, and LIN)
MDO3COMP Computer Serial Triggering and Analysis (RS-232, RS-422, RS-485
and UART)
MDO3EMBD Embedded S
erial Triggering and Analysis (I
2
C and SPI)
MDO3FLEX FlexRay Se
rial Triggering and Analysis
MDO3USB Universa
l Serial Bus Triggering and Analysis (LS, FS, H S).
High speed is decode only; available on 1 GHz models only.
MDO3LMT Limit/Mask Test Analysis
MDO3PWR
Power Me
asurement Analysis
Optional instrument upgrades
Tektronix p art number Description
MDO3AFG Arbitrary function generator
MDO3MSO
16 digital channels; includes P6316 digital probe
MDO3SA Increase spectrum analyzer input frequency range to 9 kHz - 3 GHz
MDO3SEC
Add password protected security to enable or disable all communication
ports and firmware upgrades to any MDO3000 Series oscilloscope.
Bandwidth upgrades
Upgrade the analog bandwidth on MDO3000 Series products
post-purchase. Visit www.tektronix.com for information o n available
upgrade products.
Optional accessories
Accessory Description
Tektronix part
number
TPA-BNC adapter TekVPI to TekProbe II BNC Adapter TPA-BNC
TPA-N-VPI adapter
Adapter from N connection (RF input) to
TekVPI probe.
TPA-N-BNC
TekVPI probes that work with MDO3000
Series oscilloscopes
Visit the Oscilloscope Probe and Accessory
Selector Tool on the Tektronix website at
www.tektronix.com/probes
—
NEX-HD2HEADER
Adapter that routes the channels from a Mictor
connector to 0.1 inch header pins
NEX-HD2HEA DER
TEK-USB-488 Adapter GPIB to USB Adapter TEK-USB-488
Rackmount kit Adds rackmount brackets RMD3000
Soft transit case
Protective front cover
Case for carrying instrument.
Also included with this case is a hard
plastic protective instrument front cover
(200-5052-00).
ACD3000
MDO3000 Series Oscilloscopes User Manual 3
