Tektronix MSO2024 User Manual

Acquire the Signal
FilterVu Glitch Capture Background mode
uses the highest and lowest of all the samples
contained in two consecu tive acq uisition
intervals. At fast time per division settings,
the Glitch Capture Background mode is
unavailable. This mode is also called Peak
Detect in other oscilloscopes.
Average mod e calculates the average value for
each record point over a user-specified number
of acquisitions. Average uses Sample mode for
each individual acquisition. Use Average mode
to reduce random noise.
Changing the A cquisition Mode, Record Length, and Delay Time
Use this procedure to change the acquisition mode.
1. Push Acquire.
88 DPO2000 and MSO2000 Series Oscilloscopes User Manual
