Tektronix MSO2024 User Manual

Analyze Waveform Data
Using Reference Waveforms
Create a reference waveform to store a waveform. For example, you might do this to set up a standard against which to compare
other waveforms. To use the reference waveforms:
1. Push Ref R. This brings up the lower-bezel
reference me nu.
2. Use the resulting lower-bezel menu select ions
to display or select a reference waveform.
(R1) |
(On)
3-May-07
(R2) |
(Off)
196 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
