Appendix: Warranted Specifications, Safety Certi fications, and Electromagnetic Compatibility
Appendix: Warranted Specifications, Safety Certifications, and
Electromagnetic Compatibility
Analog ba ndwidth
Oscilloscope 5 mV/div to 5 V/div with
an ambient temperature
of0°Cto40°C(0°F
to 104 °F)
5mV/divto5V/div
with an ambient
temperature of 0 °C to
50 °C (0 °F to 122 °F)
<5 mV/div
DPO2024,
MSO2024
DC to ≥200 MHz DC to ≥160 MHz
20 MHz
DPO2014,
MSO2014,
DPO2012,
MSO2012
DC to ≥100 MHz
20 MHz
Input impe dance, DC
coupled
1MΩ ±2%inparallelwith11.5pF±2pF
DC Balance ±(1 mV + 0.1 div)
DC gain accura
cy
±3%, 5 V/div thr
ough 1 0 mV/div
±4%, 5 mV/div and 2
mV/div
Offset accuracy ± [0.01 × | offset – position | + DC Balance ]
NOTE. Both t he position and constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 237
