Tektronix MSO2024 User Manual

Acquire the Signal
5. Use multipurpose kno b a to set the number of
bits to match the Word Size of the SPI bus.
Word Size
(a) 8 bits
6. Push either side bezel button to set the bit
order to match the SPI bus.
Bit Order
MS First
Bit Order
LS First
To acquire data from a CAN bus, you need to also set up th ese items:
1. If you selected CAN,pushDefine Inputs and
the desired side-bezel menu choices.
Bus
CAN
Define
Inputs
Thresholds Bit Rate
500 Kbps
B1 Label
CAN
Bus Display Event Table
104 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
