Acquire the Signal
6. Push Bit Rate, and turn multipurpose knob a
to select from the list of predefined bit rates.
Alternately, you can set the bit rate to a specific
value. To do so, select Custom, and then turn
multipurpose knob b to set the bit rate from
800 bps t o 100000 bps.
Bit Rate
(a)
19.2K bps
7. Push LIN Standard, and turn m u ltipurpose
knob a to select the app ropriate standa rd.
LIN
Standard
v1.x
8. Push IncludeParityBitswithIdto select
whether or not to include parity bits.
Include
Parity Bits
with Id
On|
Off
To acquire data from a RS-232 bus, you need to also set up these items:
108 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
