Tektronix MSO2024 User Manual

Acquire the Signal
2. Push Bit Rate, and turn multipurpose knob a to
select the appropriate bit rate.
Bit Rate
9600 bps
3. Push Data Bits and select the number to
match the bus.
Data Bits
7|
8
4. Push Parity a nd turn multipurpose knob a to
match the polarity used by the bus as None ,
Odd, or Even.
Parity
(a) None
5. Push Pack ets an d select On or Off.
Packets
On|
Off
6. Turn multipurpose knob a to select an
end-of-packet cha racter.
End of
Packet
0A
(Linefeed)
RS-232 decoding displays a stream of bytes.
You can organize the stream into packets with
an end-of-packet character
110 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
