Tektronix MSO4000B Series Technical Reference

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
The formula is calculated by measuring -3 dB bandwidth of the oscilloscope. The formula accounts for the
rise time contribution of the oscilloscope independent of the rise time of the signal source.
Instrument
50 
1 mV/div to
1.99 mV/div
50 
2 mV/div to
4.99 mV/div
50 
5 mV/div to 1 V /div
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
2 ns 1 ns 350 ps
DPO4054B
2 ns 1 ns 700 ps
DPO4034B
2ns 1ns 1ns
DPO4014B
3.5 ns 3.5 ns 3.5 ns
Instrument TPP1000 probe
10 mV/div to
19.9 mV/div
TPP1000 probe
20 mV/div to
49.8 mV/div
TPP1000 probe
50 mV/div to 10 V/div
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
2 ns 1 ns 350 ps
DPO4054B
2 ns 1 ns 700 ps
DPO4034B
2ns 1ns 1ns
Calculated rise time at
0.350/BW = t
r
,typical
DPO4014B
3.5 ns 3.5 ns 3.5 ns
Instrument TPP0500 probe
10 mV/div to
19.9 mV/div
TPP0500 probe
20 mV/div to
49.8 mV/div
TPP0500 probe
50 mV/div to 10 V/div
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
2 ns 1 ns 700 ps
DPO4054B
2 ns 1 ns 700 ps
DPO4034B
2ns 1ns 1ns
Calculated rise time at
0.350/BW = t
r
,typical
DPO4014B
3.5 ns 3.5 ns 3.5 ns
MSO4000B and DPO4000B Series Specifications and Performance Verification 7

Tektronix MSO4000B Series Specifications

General

Brand	Tektronix
Model	MSO4000B Series
Category	Test Equipment
Language	English
