Tektronix MSO4000B Series Technical Reference

Specifications
This chapter contains specifications for the MSO4000B and the DPO4000B series
oscilloscopes. All specifications are guaranteed unless noted as "typical."
Typical spec
ifications are provided for your convenience but are not guaranteed.
Specifications that are marked with the
symbol are checked in Performance
Verification.
All specifications apply to all MSO4000B and DPO4000B models unless noted
otherwise. To meet specifications, two conditions must first be met:
The oscilloscope must have been operating continuously for twenty minutes
within the specified operating temperature range. (See Table 11 on page 24.)
You must perform the Signal Path Compensation (SPC) operation described
instep2oftheSelf Test before evaluating specifications. (See page 55, Self
Test.) If the operating temperature changes by more than 1 0 °C (18 °F), you
must perform the SPC operation again.
Model Bandwi
dth
Analog
Channe
ls
Sample
Rate
(1 ch)
Sample
Rate
(2 ch)
Sample
Rate
(4 ch)
Record
Length
(1 ch)
Record
Length
(2 ch)
Record
Length
(4 ch)
MSO40
00B models:
MSO4
104B
1GHz
4
5GS/
s
5GS/
s
5GS/
s
20M 20M 20M
MSO4
104B-L
1GHz
4
5GS/
s
5GS/
s
2.5 G
S/s
5M 5M 5M
MSO
4102B
1GH
z
2
5GS
/s
5GS
/s
–
20M 20M
–
MSO
4102B-L
1GH
z
2
5GS
/s
2.5
GS/s
–
5M 5M
–
DP
O4000B models:
DP
O4104B
1G
Hz
4
5G
S/s
5G
S/s
5G
S/s
20M 20M 20M
D
PO4104B-L
1
GHz
4
5
GS/s
5
GS/s
2
.5 GS/s
5M 5M 5M
DPO4102B 1 GHz
2
5GS/s 5GS/s
–
20M 20M
–
DPO4102B-L 1 GHz
2
5 GS/s 2.5 GS/s
–
5M 5M
–
DPO4054B
500 MHz 4
2.5 GS/s 2.5 GS/s 2.5 GS/s
20M 20M 20M
DPO4034B
350 MHz 4
2.5 GS/s 2.5 GS/s 2.5 GS/s
20M 20M 20M
DPO4014B
100 MHz 4
2.5 GS/s 2.5 GS/s 2.5 GS/s
20M 20M 20M
MSO4000B and DPO4000B Series Specifications and Performance Verification 1
