Performance Verification
This chapter contains performance verification procedures for the specifications
marked with the
symbol. The following equipment, or a suitable equivalent, is
required to c
omplete these procedures.
Table 13: Required equipment
Description Minimum requirements Examples
DC voltage source 3 mV to 4 V, ±0.1% accuracy
Leveled sine wave generator
50 kHz to 1000 MHz, ±4% amplitude
accuracy
Time mark generator 80 ms period, ±1 ppm accuracy, rise time
<50ns
Fluke 9500 Oscilloscope Calibrator with a
9510 Output Module
Logic Probe Low capacitance digital probe, 16
channels.
P6616 probe; standard accessory
shipped with MSO4000B Series
oscilloscopes.
BNC-to-0.1 inch pin adapter to connect
the logic probe to the signal source.
BNC-to-0.1 inch pin adapter; female B NC
to 2x16 .01 inch pin headers.
Tektronix adapter part number
679-6240-00; to connect the Fluke
9500 to the P6616 probe.
Digital Multimeter (DMM) 0.1% accuracy or better
One 50 terminator Impedance 50 ; connectors: female
BNC input, male BNC output
Tektronix part number 011-0049-02
One 50 BNC cable
Male-to-male connectors Tektronix part number 012-0057-01
One BNC dust cap
Male, non-shorting Pasternack PE6014
You might need additional cables and adapters, depending on the actual test
equipment you use.
These procedures cover all MSO4000B and DPO4000B models. Please disregard
checks that do not apply to the specific model you are testing.
Print the test record on the following pages and use it to record the performance
test results for your oscilloscope.
N
OTE. Completion of the performance verification procedure does not update
the stored time and date of the latest successful adjustment. The date and time
are updated only when the adjustment procedures in the service manual are
successfully completed.
The performance verification procedures verify the performance of your
instrument. They do not adjust your instrument. If your instrument fails any of
the performance verification tests, you should perform the factory adjustment
procedures as described in the Tektronix MSO4000B and DPO4000B Series
Service Manual. This manual is available at www.tektronix.com/manuals.
MSO4000B and DPO4000B Series Specifications and Performance Verification 27
