Tektronix MSO4000B Series Technical Reference

Specifications
Display Speci
fications
The following table shows the display specifications for the MSO4000B Series
and DPO4000B Series oscilloscopes.
Table 7: Dis
play specifications
Characteristic Description
Display typ
e
Display area: 210.4 mm (8.28 in) (H) x 157.8 mm (6.21 in) (V), 264 mm (10.4 in) diagonal,
6-bit RGB full color, XGA (1024 x 768) TFT liquid crystal display (LCD).
Display resolution
1024 X 768 XGA display resolution
Luminance, typical
400 cd/m
2
Waveform display color scale The TFT display can support up to 262,144 colors. A subset of these colors are used for the
oscillo
scope display, all of which are fixed colors and not changeable by the user.
20 MSO4000B and DPO4000B Series Specifications and Performance Verification
