Performance Verification
DC Balance
All four-channel models for channels 3 and 4
Performance checks Vertical scale Low limit Test result High lim it
1 m V/div
-0.2 mV 0.2 mV
2 m V/div
-0.2 mV 0.2 mV
5 m V/div
-0.5 mV 0.5 mV
10 mV/div
-1 mV 1 mV
20 mV/div
-2 mV 2 mV
49.8 mV/div
-4.98 mV 4.98 mV
50 mV/div
-5 mV 5 mV
100 mV/div
-10mV 10mV
200 mV/div
-20mV 20mV
500 mV/div
-50mV 50mV
Channel 3 DC Balance,
50 ,20MHzBW
1V/div
-100 mV 100 mV
1 m V/div
-0.2 mV 0.2 mV
2 m V/div
-0.4 mV 0.4 mV
5 m V/div
-1 mV 1 mV
10 mV/div
-2 mV 2 mV
20 mV/div
-4 mV 4 mV
100 mV/div
-20mV 20mV
500 mV/div
-100 mV 100 mV
1V/div
-200 mV 200 mV
Channel 3 DC Balance,
1M,
20 MHz BW
10 V/div
-2 V 2 V
Channel 3 DC Balance,
50 , 250 MHz BW
20 mV/div
-2 mV 2 mV
Channel 3 DC Balance,
1M, 250 MHz BW
20 mV/div
-4 mV 4 mV
Channel 3 DC Balance,
50 ,FullBW
20 mV/div
-2 mV 2 mV
Channel 3 DC Balance,
1M,FullBW
20 mV/div
-4 mV 4 mV
MSO4000B and DPO4000B Series Specifications and Performance Verification 31
