Tektronix MSO4104

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Delay between
channels, full
bandwidth, typical
≤100 ps between any two channels with input impedance set to 50 Ω, DC coupling
Note: all settings in the instrument can be manually time aligned using the Probe Deskew function from
-100 ns to +100 ns with a resolution of 20 ps.
Deskew range
-100 ns to +100 ns with a resolution of 20 ps
Crosstalk (channel
isolation), typical
≥100:1 at ≤100 MHz and ≥30:1 at >100 MHz up to the rated bandwidth for any two channels having
equal Vo lts/Div settings
TekVP I Interface The probe interface allows installing, powering, compensating, and controlling a wide range of probes
offering a variety of features.
The interface is available on all front panel inputs including Aux In. Aux In only provides 1 MΩ input
impedance and does not offer 50 Ω as do the other input channels.
Total probe power
DPO4032, DPO4034, DPO4054, MSO4032, MSO4034, MSO4054: 50 W
DPO4104, MSO4104: 50 W with a derating of 0.8 W/°C for ambient temperatures ≥25 °C
Voltage Max Amperage Voltage Tolerance
5V
50 mA (250 mW) ±5%
Probe power per
channel
12 V
2 A (24 W) ±10%
Number of digitized
bits
8bits
Displayed vertically with 25 d igitization levels (DL) per division, 10.24 divisions dynamic range.
"DL" is the abbreviation for "digitization level." A DL is the smallest voltage level change that can be
resolved by an 8-bit A-D Converter. This value is a lso known as the LSB (least significant bit).
1MΩ 50 ΩSensitivity range
(coarse)
1 mV/div to 10 V/div in a 1-2-5 sequence 1 mV/div to 1 V/div in a 1-2-5 sequence
Sensitivity range (fine) 1 mV/div to 5 V /div: <-50% to >+50% of selected setting, 1 MΩ
10 V/div: <-50% to 0%, 1 M Ω
1 m V/div to 500 mV/div: <-50% to >+50% of selected setting, 50 Ω
1 V/div: <-50% to 0% , 50 Ω
Allows continuous adjustment from 1 m V/div to 10 V/div, 1 M Ω
Allows continuous adjustment from 1 mV/div to 1 V/div, 50 Ω
Sensitivity resolution
(fine), typical
≤1% of current setting
Position range ±5 divisions
The limits stated below are for ambient temperature of ≤30 °C and the bandwidth selection set to FULL.
Reduce the upper bandwidth frequency by 1% for each °C above 30 °C.
Instrument
5 mV/div to 1 V/div 2 mV/div to
4.98 mV/div
1 m V/div to
1.99 mV/div
DPO4104, MSO4104 DC to 1 GHz DC to 350 MHz DC to 200 MHz
DPO4054, MSO4054 DC to 500 MHz DC to 350 MHz DC to 200 MHz
Instrument
2 mV/div to 1 V/div 1 mV/div to 1.99 V/div
DPO4034, MSO4034 DC to 350 MHz DC to 200 MHz
Analog bandwidth,
50 Ω
DPO4032, MSO4032 DC to 350 MHz DC to 200 MHz
2 MSO4000 and DPO4000 Series Specifications and Performance Verification
