Tektronix MSO4104

Specifications
Table8:Datast
orage specifications
Characteristic Description
Nonvolatile m
emory retention time,
typical
No time limit for front-panel settings, saved waveforms, setups, and calibration constants
Real-time cl
ock
A programmab
le clock providing time in years, months, days, hours, minutes, a nd seconds
Used to stor
e reference waveforms and front-panel settings
Supply Volt
age
Form factor
Data bits
Compact Fla
sh card
Switched 3
.3 V only
Type 1 only
16 bit data
transfer
Table 9: Environmental specifications
Characteristic Description
Temperature
Operating: 0 °C to +50 °C (+32 °F to +122 °F)
Nonoperating: -20 °C to +60 °C (-4 °F to + 140 °F)
Humidity
Operating:
High: 10% to 60% relative humidity, 40 °C to 50 °C (104 °F to 122 °F)
Low: 10% to 90% relative humidity, 0 °C to 40 °C (32 °F to 104 °F)
Nonoperating:
High: 5% to 60% relative humidity, 40 °C to 60 °C (104 °F to 140 °F)
Low: 5% to 90% relative humidity, 0 °C to 40 °C (32 °F to 104 °F)
Altitude
Operating: 3,000 m (9,843 ft)
Nonoperating: 12,000 m (39,370 ft)
Pollution Degree Pollution Degree 2, indoor use only
Random vibration
Operating: 0.31 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis, 3 axes
Nonoperating: 2.46 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis, 3 axes (30 minutes
total).
14 MSO4000 and DPO4000 Series Specifications and Performance Verification
