Tektronix MSO4104

Specifications
Table 11: P6516
Digital Probe specifications
Characteristic Description
Number of channels
16
Threshold ac
curacy
±(100 mV + 3% of threshold)
Maximum sig
nal swing
6.0 V peak-t
o-peak centered around the threshold voltage
Minimum signal swing 500 mV peak-to-peak
Input resistance
20 kΩ
Input capacitance 3.0 pF typical
Temperatu
re
Operating: 0 °C to +50 °C (+32 °F to +122 °F)
Nonoperating: -55 °C to +75 °C (-67 °F to +167 °F)
Altitude
Operating: 4,500 m (15,000 ft)
Nonoper
ating: 15,000 m (50,000 ft)
Pollution Degree 2, indoor use only
Humidity
10% to 95% relative humidity
16 MSO4000 and DPO4000 Series Specifications and Performance Verification
