Tektronix MSO4104

Specifications
Table 5: Displa
yspecifications
Characteristic Description
Display type
Display area: 210.4 mm (8.28 inches) (H) x 157.8 mm (6.21 inches) (V), 264 mm
(10.4 inches) diagonal, 6-bit RGB full color, XGA (1024 x 768) TFT liquid c rystal display
(LCD).
Display resolution 1000 horizontal by 651 vertical displayed pixels
Luminance, typical
Minimum 240 cd/m
2
, typical 300 cd/m
2
Waveform display color scale The TFT display can support up t o 262,144 colors. A subset of these colors are used for the
oscillosc
ope display, all of which are fixed colors and not changeable by the customer.
Table 6: Input/Output port specifications
Characteristic Description
Ethernet interface Standard on all models: 10/100 Mbps
USB interface 1 Device and 3 Host connectors (all models)
GPIB interface Available as an optional accessory that connects to USB Device and USB Host port. with
the TEK-USB-488 GPIB to USB Adapter
Control interface is incorporated in the instrument user interface.
Video signal output
A 15 pin, XGA RGB-type connector
Probe compensator output voltage
and frequency, typical
Output voltage: 0 V to 2.5 V ±1% behind 1 kΩ ±2%
Frequency: 1 kHz ±5%
LOW TRUE; LOW to HIGH transition indicates that the trigger occurred. The logic levels are:
Characteristic
Limits
Vout (HI) ≥2.5 V open circuit; ≥1.0 V into a 50 Ω load
to ground
Trig
ger (Auxiliary) output (AUX
OUT)
Vout (LO) ≤0.7 V into a load of ≤4mA;≤0.25 V into a
50 Ω load to ground
T
able 7: Power source specifications
Characteristic Description
Source voltage 100 V to 240 V ±10%
Source frequency (90 V to 264 V) 47 Hz to 66 Hz
(100 V to 132 V) 360 Hz to 440 Hz
Fuse rating T6.3AH, 250 V
The fuse i s not customer replaceable.
MSO4000 and DPO4000 Series Specifications and Performance Verification 13
