Tektronix MSO4104

Performance Verification
Test Record
Model Serial Procedure performed by Date
Test Passed Failed
Self Test
Input Impedance
Performance checks Vertical scale Low limit Test result High limit
All models:
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 1 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 1 Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 2 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 2 Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
DPO4104, DPO4054, DPO4034, MSO4104, MSO4054, MSO4034:
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 3 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 3 Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 4 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 4, Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
DC Balance
Performance checks Vertical scale Low limit Test result High limit
All models:
1 mV/div
-0.5 mV 0.5 mV
2 mV/div
-0.5 mV 0.5 mV
100 mV/div
-20mV 20mV
Channel 1 DC Balance,
50 Ω,20MHzBW
1V/div
-200 mV 200 mV
MSO4000 and DPO4000 Series Specifications and Performance Verification 19
