Tektronix MSO4104 Technical Reference

Performance Verification
Performance checks: Digital Threshold Accuracy, MSO4000 series only
Digital
channel Threshold V V Low lim it Test result High limit
0 V -0.1 V 0.1 VD0
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD1
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD2
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD3
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD4
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD5
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD6
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD7
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD8
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD9
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD10
4 V 3.78
V
4.22
V
0 V -0.1 V 0.1 VD11
4 V 3.78 V 4.22 V
0V -0.
1V
0.1
V
D12
4 V 3.78 V 4.22 V
0 V -0.1 V 0.1 VD13
4V 3.
78 V
4.
22 V
0 V -0.1 V 0.1 VD14
4 V 3.78 V 4.22 V
0
V
-
0.1 V
0
.1 V
D
15
4 V 3.78 V 4.22 V
34 MSO4000 and DPO4000 Series Specifications and Performance Verification
