Run Application
Software
Run Applicati
on Software
Each application is available for ten free trials on your instrument. These applications provide application-specific
measurement solutions. Some examples a re described below. Additional packages may be available. Some applications
may not be available on your instrument. Contact your Tektronix representative or visit our Web site at www.tektronix.com
for m ore information.
Use ASM Advanced Event Search and Mark to e
xamine data by highlighting important events and skipping the
unimportant events.
Use DDRA Memory Bus Analysis to automatically identify DDR1, LP-DDR1, DDR2, DDR3 and GDDR3 read and writes.
Use DJA Jitter and Eye Diagram Analysis, Advanced to reliably m easure complex clock, digital, an
d serial data signals.
Use DSPT Display Port C ompliance Software to validate your IC, m otherboard, and graphics card designs.
Use DVI Compliance Test Solution Software for DVI physical layer compliance testing.
Use ET3 to perform 10/100/1000 Base-T Ethernet compliance testing.
Use FBD RTE module for FB-DIMM compliance for ≥4 GHz models.
Use HT3 HDMI Compliance Test Software for HDMI compliance testing for ≥4 GHz models.
Use IB A RTE module for In finiBand for ≥4 GHz models.
Use J2 Disk Drive Measurement Software to measure disk drive signals according to IDEMA standards.
Use JA3 Advanced Jitter Analysis Software to characterize timing performance. A nalyze jitter on contiguous clock
cycles using single-shot acquisitions.
Use LSA Serial Analysis Software for CAN/LIN protocol triggering and analysis.
Use LT Waveform Limit Testing to compare a n acquired waveform to tolerance boundaries that you set.
Use MTH Communication Mask Testing Softw are for mask compliance testing on ≥4 GHz models.
Use MTM Communication Mask Testing Software for mask compliance testing on <4 GHz models.
Use PCE RTE module for PCI-Express for ≥4 GHz models.
Use PS1 Power Solution Bundle to measure and analyze power supplies.
Use PTH , PTU or STU Se rial Protocol Trigger Software to trigger and decode 8 B/10 B data on h igh-speed serial
or data protocols. Protocol triggering u p to 6.25 GS/s.
Use PTM and PTD Serial Protocol Trigger and Decode Software to simplify validation of and isolate data dependent
faults at data rates up to 1.25 Gb/s.
Use PWR Power Measurement Software to quickly measure and analyze power dissipation in power supply switching
devices and magnetic components.
Use SLA and SLE Serial D ata Link Analysis to emulate the serial data channel, de-embed a fixture, and add or remove
transmitter equalization. SLA adds processing of waveforms with equalizations.
Use SR-COMP to enable serial triggering and analysis of RS-232/422/485/UART signals.
Use SR-EMBD to enable
serial triggering and analysis of I2C and SPI signals.
Use SR-USB to enable serial triggering and analysis of LS, FS, and HS USB s ignals.
Use SST Serial ATA and Serial Attached S CSI compliance module w ith option RTE.
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual 157
