Gaussian window

This is the default window function (see the next figure). It is unique in that the time-domain shape of an exponential Gaussian

function transforms into a Gaussian exponential shape in the frequency domain.

NOTE. This window provides optimal localization in both the time and the frequency domain

What do you want to do next?

Learn about using spectral analyzer windows.

Oscilloscope reference

732 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
