Tektronix MSO54 Printable Help

Error Message Cause Suggestion
Too few edges No of edges found in the gated
region is less than the number
of edges required for the
algorithm for calculation.
Increase the record length.
Pos clipping Vertical scale is not set
properly.
Use Power Autoset to set the vertical scale automatically.
Neg clipping Vertical scale is not set
properly.
Use Power Autoset to set the vertical scale automatically.
Invalid range Indices No data in the gated region. Make sure that the input waveforms are valid.
Empty Input Input waveform has no data. Make sure to set all the valid inputs.
Input all DC Input signal is pure DC. Change the input signal to AC or add some AC component to
DC signal.
No data in range No data in the gated region. Make sure that the input waveforms are valid.
Warning messages displayed on the Power measurement badges
Warning Message Cause Suggestion
No data in range There are no data between the
two cursors.
Place the cursors appropriately.
Warning from Frequency
measurement
Not able to measure frequency
value on the input waveform
due to noisy waveform.
Adjust Hysteresis band to compute edges properly so that
frequency can be measured. The Hysteresis values are set in
the measurement configuration menu Reference Levels panel.
Warning from RMS
measurement
Not able to measure RMS
value on the input waveform
due to noisy waveform.
Adjust Hysteresis band to compute edges properly so that RMS
can be measured. The Hysteresis values are set in the
measurement configuration menu Reference Levels panel.
Warning from MaxElement
measurement
Not able to measure MIN/MAX
value on the input waveform
due to noisy waveform.
Adjust Hysteresis band to compute edges properly so that MIN/
MAX can be measured. The Hysteresis values are set in the
measurement configuration menu Reference Levels panel.
Voltage source expected Mismatch between input
waveform and measurement.
For example if a current
waveform is used for dv/dt, this
warning is shown.
Make sure a voltage waveform is set as the voltage source
input.
Current source expected Mismatch between input
waveform and measurement.
For example if a voltage
waveform is used for di/dt, this
warning is shown.
Make sure a current waveform is set as the current source
input.
Warning from RMS
measurement
Not able to measure RMS
value on the input waveform
due to noisy waveform
Adjust the Hysteresis band to compute edges properly so that
RMS can be measured. The Hysteresis values are set in the
measurement configuration menu Reference Levels panel.
References
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 479
