Warning Message Cause Suggestion
Invalid Mask Mask is not of the standard
format, cannot have closed
mask coordinates or
intersection of the coordinate
points
Recreate the mask from the SOA mask configure table such
that inner mask coordinates do not intersect.
No data in range No data in the gated region. Make sure that the input waveforms are valid.
Input > 80% DC Input signal has higher DC
component.
Change the input signal to AC or add more AC component to
the DC signal.
Trigger Level is greater than
maximum voltage
Trigger level set is greater then
the maximum voltage.
Set the maximum voltage higher than the trigger level.
Output Voltage Level reached
before input trigger
Output is turned on before the
input or there is a spike in the
output voltage.
Make sure that the input and output voltage are not
interchanged, output is dependent on the input, and run the
measurement again.
Information messages displayed on the Power measurement badges
Information messages Description
Actual Input Level used in calculation is n V. In Turn On Time and Turn Off Time measurements, if the input
level is not equal to the maximum of input waveform (n), the
maximum of the input waveform is used for computation and
the same is displayed as the information message.
Actual Output x Level used in calculation is n V. In Turn On Time and Turn Off Time measurements, if the
output x level is not equal to the maximum output x waveform
(x), the maximum of the output x waveform is used for
computation and the same is displayed as the information
message.
