Install your ins

trument

Powering on the instrument

Power supply r

equirements

Source voltage and frequency Power consumption

MSO70000C/DX and DPO70000C/DX Series:

100–240 V

RMS

±10%, 50–60 Hz

or 115 V

RMS

±1

0%, 400 Hz. CAT II

≤1100 VA

DPO7000C Se

ries:

100–240 V

RMS

±10%, 47–63 Hz

or 115 V

RMS

±10%, 400 Hz

550 Watts ma

ximum

MSO5000B and DPO5000B Series:

100–240 V

RMS

±10% 50–60 Hz

115V440Hz

275 Watts maximum

MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series User Manual 7
