Instructions for the demo board
1.
Press the On button to turn on the
demo board.
2.
Set the reference to INT (internal
reference).
3.
Set the run mode to FREE RUN.
4.
Click the ROW and COLUMN buttons
to select CW as the signal to
generate.
demoboard1
1
2
3
4
Demo instructions
12
RSA306 Self-Guided Demo
