Tektronix RSA306 Self Help Guide

Instructions for the RSA306
1. Double click the SignalVu-PC icon on
the PC desktop to start the
application.
screenicon
1
2. Click Live Link on the menu bar to
view the drop down menu. Click
Search for Instrument.
A notification will briefly appear
stating that the instrument was
found.
3. Click Connect To Instrument. Select
RSA306@USB USB::0. First-time
connection to the analyzer may take
up to 10 seconds.
rsaconnect
2 3
Demo instructions
RSA306 Self-Guided Demo 13
