8. Under the Bitmap Scale tab, set the
Max scale to 3% for the DPX
Spectrum display.
Demo5-Step8
8
9. Under the Ampl Scale tab, set the Min
color scale to -80 dBm for the
DPXogram display.
Demo5-Step9
9
Demo instructions
RSA306 Self-Guided Demo 47
