Tektronix RSA306 Self Help Guide

10. Under the Prefs tab, enable Show
parameter readouts.
Demo5-Step10
10
11. Click Stop to pause the measurement. Right click the DPXogram screen, select Add marker, and drag the
marker to one hopping signal. Then add another marker and drag it to the closest hopping signal. The delta
marker will show the time between two hopping signals is about 1.25 s, or the hop occurs every 1.25 second.
12. You can set the size of the DPX spectrogram by selecting the divider bar between the displays and moving it
up or down to add area to the display of interest.
Demo instructions
48 RSA306 Self-Guided Demo
