Removal and installation procedures
Removal and installation procedures
This subsection contains procedures for the removal and installation of all
customer-replaceable mechanical and ele ctrical modules.
Preparation
WARNING. Before doing this or any other procedure in this manual, read the
Safety Summary found at the beginning of this manual. Also, to prevent possible
injury to service personnel or damage to the instrument components, read
Installation in the RSA5100B Series Real-Time Signal Analyzers Quick Start User
Manual, a
vailable on the Web at www.tektronix.com/manuals, and Preventing
ESD in this section.
This subsection contains the following items:
Preparatory information that you need to properly do the procedures that
follow.
A list of tools required to remove and disassemble all modules.
Procedures for removal and reinstallation of the electrical and mechanical
modules.
WARNING. Before doing any procedure in this subsection, disconnect the power
cord from the line voltage source. Failure to do so could cause serious injury
or death.
NOTE. Read the Equipment Required section for a list of the tools needed to
remove and install modules in this instrument. (See Table 3-3 on page 3-8.) Read
the cleaning procedure before disassembling the instrument for cleaning.
RSA5100B Series Service Manual 3–7
