Replaceable parts
Table 4-4: Powe
r supply and hard drives
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
4-4-1 119-6986-06 1
POWER SUPPLY; AC-DC;460W;+3.3V 40A, +5V 34A, +12V 25A, -12V 1A, +5VSB
2A;90-264VAC
, 47-440HZ
-2 211-0718-00 6
SCREW, MACHI
NE; 6-32 X 0.312, FLH100, STEEL, ZINC FINISH, T-10 TORX
-3 407-5477-00 1
BRACKET; POW
ER SUPPLY; SAFETY CONTROLLED
-4 441-2619-00 1
CHASSIS; DR
IVE TRAY
-5
348-1835-00 4
GROMMET; VI
BRATION ISOLATION
-6 211-1050-00 9
SCREW, MACH
INE; 6-32 X 0.312 L, PNH, STEEL, ZINC FINISH, T15
-7
407-5472-00 1
BRACKET; H
ARD DRIVE, 3.5 INCH HARD DRIVE
-8 850-0264-00 1
DRIVE ASSE
MBLY; INTERNAL FIXED DRIVE,PROGRAMMED
1197524XX;RSA5103B/5106B/5115B/5126B, OPTION 59
-9 850-0263
-00
1
DISK DRIVE ASSY; PROGM 119825000,SS REMOVEABLE HARD
DRIVE,RSA5103B/5106B/5115B/5126B, OPTION 56
NOTE. This is a replacement drive. To order a s pare drive order:
RSA5BUP
SSD.
-10 407-5473-00 1
BRACKET
; HARD DRIVE, 2.5 INCH REMOVABLE
-11 441-2620-01 1
CHASSIS
; DRIVE BAY FRAME TOP
-12 407-5337-00 1
HDD CAB
LE BRACKET
-13 174-5349-00 1
CABLE A
SSY; SATA COMBO, HARD DRIVE CABLE WITH LATCH
-14 174-5089-00 1
CA ASSY
, PWR; DISCRETE, D IG INTERFACE, 2X10, 18AWG; SAFETY CONTROLLED
-15 174-5090-00 1
CA ASS
Y, PWR; DISCRETE, DIG INTERFACE, 2X6, 20AWG; SAFETY CONTROLLED
-16 174-5101-00 1
CA ASS
Y, SP; IDC, RIBBON, AUDIO COM Express PC TO DIG INTERF, 2X5, 2MM;
SAFETY CONTROLLED
-17 174-
5100-00
1
CA ASSY, PWR; IDC, RIBBON, PWR CONV TO BULKHEAD, 2X25, 0.100 CTR; SAFETY
CONTROLLED
-18 863-0592-xx 1
CIRCUIT BD ASSY; POWER CONVERSION
-19 211-0510-00 8
SCREW, MACHINE; 6-32 X 0.375, PNH, ZINC PLATED STEEL, T15
-20 200-5135-00 1
COVER, POWER SUPPLY
-21 174-5227-00 1
CABLE ASSY;LINE FILTER; SAFETY CONTROLLED
-22 211-0380-00 2
SCREW, MACHINE; 4-40 X 0.375, FLH, STEEL, ZINC FINISH, T8
4–10 RSA5100B Series Service Manual
