Replaceable parts
Table 4-5: Uppe
r deck fans, misc. cables
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
4-5-1 211-1050-00 16
SCREW,MACHINE; 6-32 X 0.312 L,PNH, STEEL, ZINC FINISH, T10, TORX
436-0424-00 1
ASSY,FAN TRAY; WITH FANS MOUNTED (UPPER DECK); SAFETY CONTROLLED
119-7182-00 2
FAN, TUBEAXIAL; 12VDC, 0.40A, 4.80W, 2500RPM, 100.6CFM, 120MM, LEADS W/CONN;
SAFETY CONTR
OLLED (SUBPARTS OF 436-0424-00)
-2
407-5062-00 1
BRACKET; FA
N MOUNTING,UPPER DECK; SAFETY CONTROLLED (SUBPART OF
436-0424-00)
-3 174-5212-0
0
1
CA ASSY,SP; IDC, RIBBON, CONTROL LINES, BULKHEAD TO RF INTERFACE,
2X7,0.100 CTR SAFETY CONTROLLED
-4 174-5201-00 1
CA ASSY,SP; IDC, RIBBON, GPIB, DIG INTF TO REAR PANEL; SAFETY CONTROLLED
-5
213-1061-00 2
JACKSCREW; 6-32 EXT THD, M3.5 X 0.6-6 INT THD, 410 SS
-6 407-5055-00 1
BRACKET ASSY; SPEAKER
-7
119-7172-00 1
SPEAKER; DYNAMIC; 28MM DIA, 8 OHM, 600-7KHZ, MYLAR CONE, MG ELECT
288BB20 W
ITH 28 INCH CABLE
-8 407-5480-00 1
BRACKET
; BNC ADAPTER
-9 174-5066-00 2
CA ASSY,
RF,FLEX-COAX; FRONT PANEL ACQ
4–12 RSA5100B Series Service Manual
