Tektronix RSA5BUP Technical Reference

Performance Verification
RF Input Flatn e
ss
Low limit Test Result High limit
Attenuator = 10 dB
10 MHz - 3 GHz
(Preamp OFF)
–0.35 dB +0.35 dB
10 MHz - 3 GHz
(Preamp ON,
RSA5103B/5106B)
–0.5 dB +0.5 dB
3GHz-6.2GHz
(Preamp OFF
,
RSA5106B/5115B/5126B)
–0.5 dB +0.5 dB
3GHz–6.2GHz
(Preamp ON,
RSA5106B
/5115B/5126B)
–0.7 dB +0.7 dB
6.2 GHz - 1
5GHz
(Preamp OFF,
RSA5115B/5126B)
–1.0 dB +1.0 dB
6.2GHz-15GHz
(Pream
pON,
RSA5115B/5126B
only)
–1.0 dB +1.0 dB
15 GHz - 26.5 GHz
(Prea
mp OFF,
RSA5126B only)
–1.2 dB +1.2 dB
15 GHz – 26.5 GHz
(Preamp ON,
RSA5
126B only)
–1.2 d
B
+1.2 d
B
LF Input Path Flatness Low lim it Test Result High limit
Attenuator = 10 dB
10 MHz - 32 MHz,
(Preamp OFF)
-0.2 dB +0.2 dB
10 MHz - 32 MHz,
(Preamp ON)
-0.5 dB +0.5 dB
Absolute accuracy at calibration point Low limit Test Result High lim it
Absolute amplitude SP 300 kHz, RF Path
–0.31 dB +0.31 dB
Absolute amplitude SP 1 MHz, R F Path
–0.31 dB +0.31 dB
Absolute amplitude SP 25.1 M Hz, RF Path
–0.31 dB +0.31 dB
Absolute amplitude SP 1 MHz, LF Path
–0.31 dB +0.31 dB
Absolute accuracy at calibration point,
Preamp ON Low limit Test Result High limit
Absolute amplitude SP 300 kHz, RF Path
–0.5 dB +0.5 dB
Absolute amplitude SP 1 MHz, R F Path
–0.5 dB +0.5 dB
RSA5100B Series Technical Reference 135
