Specifications
Table 10: Noise and distortion
1
(cont.)
Characteristic Description
Preamp ON (Opt. 50/51)
Specificatio
n
Typical
1MHzto
32 MHz, LF
Band
–158 dBm/Hz
(RSA5103B/5106B)
–160 dBm/Hz
(RSA5103B/5106B)
1MHzto
10 MHz
–158 dBm/Hz –160 dBm/Hz
10 MHz to
2GHz
–164 dBm/Hz –167 dBm/Hz
2GHzto
3GHz
–163 dBm/Hz –165 dBm/Hz
3GHzto
6.2 GHz
–162 dBm/Hz
(RSA510
6B)
–164 dBm/Hz (RSA5106B)
3GHzto
4GHz
–160 dB
m/Hz
(RSA5115B/5126B)
–163 dB
m/Hz
(RSA5115B/5126B)
4GHzto
6.2 GHz
–159 dBm/Hz
(RSA5115B/5126B)
–162 dBm/Hz
(RSA5115B/5126B)
6.2 GHz to
13 GHz
–159 dBm/Hz
(RSA5
115B/5126B)
–162 dBm/Hz
(RSA5
115B/5126B)
13 GH
zto
23 GHz
–157
dBm/Hz
(RSA5115B/5126B)
–160
dBm/Hz
(RSA5115B/5126B)
23 GHz to
26.5 GHz
–153 dBm/Hz
(RSA5126B)
–156 dBm/Hz (RSA5126B)
1
All noise and distortion measurements are made with Preamp OFF except where noted.
2
Maximize Dynamic Range, “RF & IF Optimization” Mode, Span: 5 MHz.
3
The 1 dB compression point for the RF conversion system cannot be measured from outside the instrument, nor can signals get near it in operation. This is
because the A/D converter will clip before the 1 dB compression is reached.
4
Each signal level –25 dBm at the RF input. 1 MHz tone separation. Attenuator = 0, Ref Level = –20 dBm.
5
Each signal level –50 dBm at the RF input. 1 MHz tone separation. Attenuator = 0, Ref Level = –45 dBm.
Table 11: Channel Response – Amplitude & Phase Flatness (Standard/Option B40)
for RSA5103B/5106B:
Frequency range Span Amplitude flatness Phase flatness
Specification
Typical, RMS Typical, RMS
0.01 GHz to 6.2 GHz
300 kHz
1
±0.10 dB 0.05 dB
0.1°
0.03 GHz to 6.2 GHz
25 MHz ±0.30 dB 0.20 dB
0.5°
0.03 GHz to 6.2 GHz
40 MHz
2
±0.30 dB 0.20 dB
0.5°
0.07 GHz to 3.0 GHz
85 MHz
3
±0.50 dB 0.30 dB
1.5°
>3.0 G Hz to 6.2 GHz
85 MHz
3
±0.50 dB 0.40 dB
1.5°
0.1 GHz to 6.2 GHz
165 MHz
4
±0.50 dB 0.40 dB
1.5°
0.001 GHz to 0.032 GHz
(LF band)
20 MHz ±0.40 dB 0.30 dB
0.5°
14 RSA5100B Series Technical Reference
