Specifications
Atten=0dB
Pulse width 300 ns.
PRI 300 us.
Duty cycle 0.001
Absolute Frequency Error determined over center 50% of pulse.
13
For conditions of:
Linear Chirpe
dpulses
For signal type: Linear Chirp, Peak-to-Peak Chirp Deviation: 0.8 x Measurement BW.
Frequency Estimation = Manual
Pulse ON power –20 dBm
Signal peak at Ref Lvl.
Atten=0dB
Pulse width
100 ns.
PRI 300 us.
Duty cycle 0.0003
t
meas
–t
reference
10 ms
Absolute Frequency Error determined over center 50% of pulse.
14
For conditions of:
Linear Chirp
ed pulses
For signal type: Linear Chirp, Peak-to-Peak Chirp Deviation: 0.8 x Measurement BW.
Frequency Estimation = Manual
Pulse ON power –20 dBm
Signal peak at Ref Lvl.
Atten=0dB
Pulse width
300 ns.
PRI 1000 us.
Duty cycle 0.0003
t
meas
–t
reference
10 ms
Absolute Frequency Error determined over center 50% of pulse.
Table 18: Impulse response
Characteristic Description
15 to 40 dBImpulse Response Measurement Range
(nominal)
Across the width of the chirp
±2 dB
1
Impulse Response Measurement
Accuracy (nominal)
For a signal 40 dB in amplitude and delayed 1% to 40% of the chirp width
Impulse Response Weighting Taylor Window
1
Chirp width 100 MHz, pulse width 10 s, minimum signal delay 1% of pulse width or 10/(chirp bandwidth), whichever is greater, and minimum 2000 sample
points during pulse on-time.
24 RSA5100B Series Technical Reference
