Table 11: Channel Response – Amplitude & Phas e Flatness ( Standard/Option B 40) (cont.)
for RSA5103B/5106B:
Frequency range Span Amplitude fl atness Phase flatness
Use Flattop Window for maximum CW amplitude verification accuracy.
for RSA5115B/5126B:
Frequency range Span Amplitude fl atness Phase flatness
Specifica
tion
Typical, RMS Typical, RMS
>6.2 GHz t
o 15/26 GHz
300 kHz
1
±0.10 dB 0.05 dB
0.2 °
>6.2 GHz
to 15/26 GHz
25/40 k
Hz
±0.50 dB 0.40 dB
1.0 °
>6.2 GH
z to 15/26 GHz
80 MHz ±0.75 dB 0.70 dB
1.5 °
>6.2 GH
z to 15/26 GHz
110 MHz
4
±1.0 dB 0.70 dB
1.5 °
>6.2 G
Hz to 15/26 GHz
160 MHz
4
±1.0 dB 0.70 dB
1.5 °
1
Hi Dyn Range mode.
2
Option B40/Option B85/Option B16x
3
Option B85 only
4
Option B16x only
Table 12: Channel Response – Amplitude & Phase Flatness (Option B85)
Frequency range Span Amplitude flatness Phase flatness
Specification
Typical, RMS Typical, RMS
0.07 GHz to 3 GHz
85 MHz ±0.50 dB 0.30 dB
1.5°
3GHzto6.2GHz
85 MHz ±0.50 dB 0.40 dB
1.5°
Table 13: Channel response
1
Characteristic Description
BW 300 kHz
2
±0.1 dB
300 kHz < BW  10 MHz
2
±0.2 dB
10 MHz < BW  25/40 MHz
2
±0.4 dB
40 MHz < BW  85 MHz
2
±0.5 dB
85 MHz < BW  110 MHz
2
±0.5 dB
Amplitude Flatness
110 MHz < BW  160 MHz
2
±0.5 dB
BW 300 kHz
2
±0.1°
300 kHz < B W  10 MHz
2
±0.2°
10 MHz < BW  20 MHz
2
±0.75°
20 MHz < BW  25/40 MHz
2
±0.75°
40 MHz < BW  85 MHz
2
±2.0°
Phase Linearity, typical
110 MHz < BW  160 MHz
2
±2.0°
1
The BW value used in this table is the bandwidth of the channel. RF A ttenuator = 10 dB. Use Flattop Window for maximum CW amplitude verification accuracy.
2
After calibration and normalization, CF = 200 MHz.
